Description

Application
Engine room, Work shop, Toilet, Industrial areas

Protection degree IP56

Materials
■Body : PBT(Poly Butylene Terephthalate) / brass
■Guard : Clear polycarbonate / cast brass
■Globe : Clear glass / Polycarbonate
■Stainless steel screen can be installed additionally

Finish
■Body : Light green color (Munsell No. 7.5BG 7/2)

Light Source
■Base : E26 / E27
■LED Bulb : 9 W
■LED CCT range : 2700 K – 6500 K
*CCT : Correlated Color Temperature

Equipment
– Two cable glands 20a~c (Diameter: Max. 16mm cable)

Electrical
■ AC 220 – 240 V, 50/60 Hz
Option
■AC 100 – TD V, 50/60 Hz

Warranty Period
■ 5 years
