Description

Protection degree IP66 / IP67

Materials
■Body : Stainless steel sheet deep drawn
■Front glass : Heat and impact resistant glass
■Latch : Stainless steel

Finish
■Body : White epoxy powder coat and stove enameled
(Munsell No. N-9.3)

Light Source
■Power LED : 30 W
■ TIR Lens : 60°
*TIR : Total Internal Reflection

Equipment
■ Two Cable glands M24 (Diameter: Max. 17 mm cable)
■ Vertical adjust: Up 40°, Down 80°

Electrical
■ AC 220 – 240 V, 50/60 Hz
■ Ambient Temperature : -30 °C ~ 45 °C
Option
■AC 100 – TH V, 50/60 Hz
Warranty Period
■5 years
