Description

Protection degree IP66 / IP67

Materials
■Body : Aluminium die casting
■Front glass : Heat and impact resistant glass

Finish
■Body : White epoxy powder coat and stove enamelled
(Munsell No. N-9.3)

Light Source
■Power LED : 125 W
■ TIR Lens : 60°
*TIR : Total Internal Reflection

Equipment
■ Two Cable glands M25
(Diameter: Max. 13 ~ 18 mm cable)
■ Vertical adjust (Up: 40°, Down: 60°)

Electrical
■ AC 220 ~ 240 V, 50/60 Hz
■ Ambient Temperature : -30 °C ~ 45 °C

Option
■ AC 100 ~ 277 V, 50/60 Hz

Warranty Period
■5 years
