Description

Application
■ Helicopter landing area, especially Offshore Helideck

Protection degree IP66 / IP67

Explosion protection
■Ex eb mb op is IIC T5 Gb (-40 °C < Ta < +55 °C)
■Standard : CAP 437 / ICAO Annex 14
IEC 60079-0 / 7 / 18 / 28

Materials
■Body : Marine grade aluminum (AC7A)
■Globe : Engineering Plastic (fl) Clear
Diffuser Polycarbonate

Finish
■Body: Epoxy powder coat & stove enamelled

Light Source
■Wattage of LED module : 12 W
■Number of LED modules : 2EA
■LED color: Green, Red, Blue
(acc. to CAP 437 / ICAO Annex 14)

Equipment
■Cable gland : M20, M25, NPT1/2″, NPT3/4″

Electrical
■Input Voltage Range : DC 24 V or AC 100 ~ 240 V
■Input Frequency Range : DC or 50/60 Hz
■Input Current: 0.5 A
■Power consumption : about 12 W
