Description

Application
■Helicopter landing area
■Especially offshore helideck

Protection degree IP66 / IP67

Explosion protection
■Ex eb mb op is IIC T4 Gb (-40 °C < Ta < +55 °C)
■Standard : CAP 437 / ICAO Annex 14
IEC 60079-0 / 7 / 18 / 28

Materials
■Body : Marine grade aluminum (AC7A)
■Mounting bracket: Stainless steel (STS316L)
■ Transparent parts : Tempered glass

Finish
■Body : Epoxy powder coat

Light Source
■ Automatically switched in the event of LED(s) failure
■Color: White

Equipment
■Cable gland : M20, M25, NPT 3/4″, NPT 1″
Electrical
■Input voltage : AC 100 ~ 240 V , 50/60Hz
■Power consumption : 38 W

Option
■NVG compatible light mode
*NVG : Night Vision Goggle System

Warranty Period
■10 years
