Description

Protection degree IP66 / IP67
■Explosion protection :
Ex de IIC T3 Gb (400 W) / Ex de IIC T4 Gb (250W, Sodium)
-25 °C < Ta < 45 °C / -25 °C < Ta < 50 °C (Halogen)
■Standard : IEC 60079-0 / IEC 60079-1 / IEC 60079-7

Materials
■Body : Aluminium die casting (LM6)
■Globe : Hard and impact resistant glass

Finish
■Body :Yellow epoxy powder coat and stove enamelled

Equipment
■H.P Sodium Lamp : 250 W / 400 W
■Metal Halide Lamp : 250 W / 400 W
■Halogen Lamp : 500 W
■Lamp base : E39 / E40
– Two cable glands : M20
■Built-in Ballast (Metal Halide , Sodium)

Electrical
■ AC 220 V, 50/60 Hz
AC 230 M, 50/60 Hz (Halogen)
Option
■Cable gland : M25, NPT1/2″, NPT3/4″
■ Anti-vibration packing
■AC 230 V, 50/60 Hz

(PF-25SBX2 / PF-40SBX2, PF-25MHBX2 / PF-40MHBX2)
■ AC 120 V / 127 Vz 60 Hz (PF-40MHBX2)
■ AC 120 V / 125 V / 130 V, 50/60 Hz (PF-50HBX2)
