Description

Protection degree IP56

Materials
■Body : Stainless steel 316
■ Arm : Stainless steel 316
■Front glass : Heat and impact resistant glass
■Latch : Stainless steel 316

Finish
■Body : White epoxy powder coat and stove enameled
(Munsell No. N-9.3)

Equipment
■LED : 7 W module x 7ea / 7 W module x 22ea
(Indirect method with reflector)
■Cable : One cable gland M24
(Diameter: Max. 17 mm cable)

Low base unit with cabin control
■Horizontal rotation : ±180°
■ Vertical movement: up(35°), down(35°)

Electrical
■ AC 100-240 V , 50/60 Hz
■Operating Temperature Range : -30 °C – 45 °C

Peak intensity
■PS60LL-J : 1,040,000 cd / 1 lux at 1,020 m
■PS170LL-J : 3,300,000 cd / 1 lux at 1,816 m

Option
■Dimming (0% / 50% / 75% / 100%)

Warranty Period
■5 years
